Vulcan VCBB36B 36" Gas Range W/ Full Charbroiler & Storage Base, Natural Gas
Great for kitchens with limited space, the Vulcan VCBB36B heavy-duty gas range features a 36-inch-wide charbroiler that rests on a storage cabinet. So users can adjust heat for specific sections and create smoky flavors with appetizing grill lines, each of the charbroiler's six cast iron burners have corresponding pilot lights, controls, and slanted, lift-off cast iron grates. For uniform heat distribution along the unit's top, it's built with char radiants and stainless steel supercharger burner dividers. To ease cleaning between uses, the grates can be lifted off, while the extra-deep crumb tray collects food debris during cooking.
The Vulcan VCBB36B commercial range's cabinet base provides convenient storage for condiments, spices, cooking utensils, and other frequently used supplies; its stainless steel door ensures the stored contents remain concealed. This unit measures 36 inches wide by 41 7/8inches deep by 40 1/2 inches high overall and is positioned on 6-inch stainless steel legs that can be raised or lowered to stabilize it on bumpy or sloped flooring. Because its front, front top ledge, burner box, sides, base, and stub back are made of stainless steel, it resists denting, rusting, and scratching and provides long-term durability in the back of house.
- Featured in the V series
- 36-in.-wide charbroiler with 6 burners
- Individual pilot lights and controls for each burner
- Char radiants
- Stainless steel supercharger burner divider panels
- 6 sloped, heavy-duty cast iron grates
- Extra-deep stainless steel crumb tray
- Stainless steel front, front top ledge, burner box, sides, base, and stub back
- Resists denting, scratching, and corroding
- 4-in. stub riser
- Cabinet base with stainless steel door
- Adjustable 6-in. stainless steel legs
- 99,000 BTU
- 36 in. W x 41 7/8 in. D x 40 1/2 in. H
- Powered by natural gas
- 1 1/4-in. diameter front gas manifold
- 3/4-in. rear gas connection
Specifications
| Manufacturer | Vulcan |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Heavy Duty |
| Base | Storage |
| BTU / Burner | 16500 |
| Burner Configuration | Standard |
| Burner Style | None |
| Burner Type(s) | None |
| Charbroiler Location | Full |
| Charbroiler Width (in) | 36 |
| Controls | Manual |
| Depth (in) | 36.75 |
| Gas Inlet Size | 1.25 |
| Gas Type | NG |
| Heat | Gas |
| Height (in) | 36 |
| Installation Type | Freestanding |
| Number of Burners | None |
| Number of Ovens | No Oven |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Racks per Standard Oven | No Rack |
| Range Configuration | Charbroiler |
| Rating | Best |
| Series | V Series |
| Total BTU | 99000 |
| Vent | Stub Riser |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 504.00 |
