Vulcan 3GR45MF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane
Designed with three batteries, the Vulcan 3GR45MF gas fryer's vats each accommodate 45 to 50 pounds of oila€”great for frying breaded fish, chicken tenders, and fries in high-volume establishments. Its four heat exchanger tubes spread heat evenly throughout the oil; because it has a large heat transfer area, it's energy efficient. The durable stainless steel cabinet and tank endure rigorous use, while its twin fry baskets reduce user burns with plastic-coated handles. To collect loose sediment so it doesn't burn, the cold zone boasts a V-shaped design. This floor model's millivolt thermostat sets temperatures between 200 and 400 degrees Fahrenheit. It includes a tank brush, stainless steel crumb scoop, and a clean-out rod to streamline cleaning. It also sits on four 6-inch casters that ease mobility for maintenance and cleaning; two of these casters lock for stationary placement.
To reducet fire risks, the Vulcan 3GR45MF deep fryer has a hi-limit shut off that turns off the gas burners when oil reaches extreme temperatures. It operates with liquid propane, outputs 360,000 BTUs per hour, and features a combination gas shut-off valve and pilot safety system for enhanced safety. Operators can prolong the oil's life with the Kleenscreen Plus® filtration system, which filters oil through its 270-square-inch stainless steel mesh screen and recirculates it to be reused with minimal flavor transfer. The 18-gauge stainless steel filter pan weighs 20 1/2 pounds, is built with lift handles, and sits on drawer slides for simple handling. Its 1 1/4-inch ball-type drain valve includes an interlock switch that automatically powers off the gas burners when the valve is draining oil. For simplified tank cleaning, its Boil Out ByPass® the system enables employees to boil water and cleaning solution in the vat and then remove the liquids without interfering with other fryer parts; the pan and screen are also dishwasher safe.
- Part of the GR series
- 45- to 50-lb. capacity per vat
- 3 batteries
- Floor model
- Stainless steel cabinet and tank
- 4 heat exchanger tubes
- V-shaped cold zone
- 1 1/4-in. full-port, ball-type drain valve
- Twin fry basket with plastic-coated handles
- Millivolt thermostat control temperature range: 200 to 400 degrees F
- Includes tank brush, stainless steel crumb scoop, and clean-out rod
- (4) 6-in. casters (2 locking)
- Hi-limit shut off
- 360,000 BTU
- Combination gas shut-off valve and pilot safety system
- Drain valve interlock switch automatically turns off gas burners if drain valve is opened
- 20 1/2-lb. seamless filter pan made of 18-ga. stainless steel
- 270-sq-in. stainless steel mesh filter screen is double sided
- Boil Out ByPass removes boil-out solution from vat
- Dishwasher-safe filter pan and screen
- Pan has lift handles and is placed on drawer slides 70-lb. frying compound capacity 2. Motor and pump circulate oil at 8 gallons per minute
- One-touch push-button switch activates filter pump controls
- High-temperature discard hose
- Overall: 46 1/2 in. W x 30 1/8 in. D x 46 1/4 in. H
- LP gas
- 6 A, 1/3 HP
- 120 V/60 Hz/1 ph, includes cord with NEMA 5-15P plug
- 1/2-in. ID and 3/4-in. OD rear gas connection
Specifications
| Manufacturer | Vulcan |
| Baskets | 2 |
| BTU per Fryer | 120000 |
| Capacity (lbs) | 150 |
| Food Type | Breaded |
| Frypot Style | Tube Type |
| Gas Type | LP |
| Heat | Gas |
| NEMA | 5-15P |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 150 |
| Oil Capacity/Fryer (lb) | 50 |
| Product | Gas Fryers |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | 3GR45M Series |
| Special Features | Casters Included - Uninstalled |
| Type | Floor Model |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Width (in) | 46.5 |
| Weight | 695.00 |
