Vulcan 3GR85MF Gas Fryer - (3) 90 Lb Vats, Floor Model, Liquid Propane
Because the Vulcan 3GR85MF gas fryer features integrated millivolt controls behind the door, it's simple to operate, which minimizes necessary staff training. Furthermore, it sits on four 6-inch casters, so it can be easily installed and maneuvered for cleaning and maintenance. This unit measures 63 inches wide by 34 3/8 inches deep by 46 1/4 inches high and is constructed of stainless steel to match other kitchen equipment while avoiding dents and scratches. To ease cleaning, this fry tank includes a 1 1/4-inch full port ball type drain valve, tank brush, and clean-out rod.
The Vulcan 3GR85MF commercial gas fryer features three 90-pound-capacity vats to promote high-volume production of fries, mozzarella sticks, and hushpuppies or breaded chicken, fish, pork loin, and other meats. To ease retrieval and removal of cooked products, its 19 1/2-inch-wide by 18 1/4-inch-deep fry tanks each hold two twin baskets that feature plastic-coated handles to reduce heat transfer to palms. This unit maintains temperatures between 200 and 400 degrees Fahrenheit and can extend oil life with its KleenScreen Plus® filtration feature. This filtration system works across the three-fryer battery system and has a Boil Out ByPass® that effectively removes boil-out solution from the tanks without contacting the drain manifold, motor, or filter pan. The filter's stainless steel mesh screen filters from both sides, while its motor circulates oil at 8 gallons per minute.
- Part of the 3GR85M series
- 3 fry pots
- Capacity per fry pot: 85-90 lb. (255-270 lb. total)
- Stainless steel cabinet and fry tank
- Twin baskets feature plastic-coated handles
- (4) 6-in. adjustable casters
- Includes tank brush and clean-out rod
- Millivolt thermostat controls
- Temperature range: 200-400 degrees F
- Hi-limit shutoff
- Combination gas shut-off valve and pilot system for user safety
- KleenScreen PLUS filtration system
- Boil-out ByPass
- Motor and pump circulate compound at 8 gal. per minute
- 18-ga. stainless steel filter pan
- Stainless steel filter mesh screen
- 1 1/4-in. port ball type drain valve
- Interlock switch
- Twin baskets: 8 3/4 in. W x 16 3/4 in. D x 6 in. H
- Fry tanks: 19 1/2 in. W x 18 1/4 in. D
- Overall: 63 in. W x 34 3/8 in. D x 46 1/4 in. H
- 6 A, 1/3 HP
- 115 V/60 Hz/1 ph
- LP gas powered
- 450,000 BTU
Specifications
| Manufacturer | Vulcan |
| Baskets | 2 |
| BTU per Fryer | 150000 |
| Capacity (lbs) | 270 |
| Food Type | Breaded |
| Frypot Style | Tube Type |
| Gas Type | LP |
| Heat | Gas |
| NEMA | 5-15P |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 270 |
| Oil Capacity/Fryer (lb) | 90 |
| Product | Gas Fryers |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | 3GR85M Series |
| Special Features | Casters Included - Uninstalled |
| Type | Floor Model |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Width (in) | 63 |
| Weight | 922.00 |
