Vulcan 3TR45CF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane

SKU 3TR45CF-LP
Original price $0.00 - Original price $0.00
Original price $0.00
$48,765.00
$48,765.00 - $48,765.00
Current price $48,765.00

The Vulcan 3TR45CF gas fryer features three total vats that hold 45 to 50 pounds of oil each. Part of the PowerFry3® series, this unit features programmable controls that assist operators with adjusting temperatures between 200 and 390 degrees Fahrenheit. Its SoftStart® heat transfer system prevents scorching and conserves energy by lowering output to 105,000 BTU per hour during startup, while its ThreePass® heat transfer system yields 60 percent cooking efficiency and 72 percent thermal efficiency. To drop and retrieve breaded foods, each vat has twin baskets with plastic-coated handles.

Equipped with KleenScreen PLUS® technology, the Vulcan 3TR45CF gas fryer offers adept filtration that extends oil life by 200 to 400 percent. This system's 1/3-horsepower motor circulates oil at 8 gallons per minute through both sides of a stainless steel filtration screen to remove sediment and small particulate that could affect oil life and taste. When oil needs to be replaced, it can be drained through the 1 1/4-inch port ball type drain valve into the 18-gauge stainless steel filter pan. Overall, this unit measures 46 1/2 inches wide by 30 1/8-inches-deep by 47 1/4 inches high and its cabinet and fry tank are constructed of stainless steel to reduce marring to the structure. It sits on a set of four 6-inch casters to ease maneuvering for cleaning or maintenance.

  • Part of the PowerFry3® series
  • 3-fryer battery
  • Total capacity: 135-150 lb. (45-50 lb. per fryer)
  • Twin baskets feature plastic-coated handles
  • Stainless steel cabinet and fry tank
  • (4) 6-in. adjustable casters
  • Includes tank brush and clean-out rod

  • Temperature range: 200-390 degrees F
  • Programmable computer controls with melt cycles
  • ThreePass heat transfer system
  • Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
  • SoftStart electronic ignition system

  • KleenScreen PLUS filtration system
  • 18-ga. stainless steel filter pan
  • Stainless steel filter mesh screen
  • 1 1/4-in. port ball type drain valve
  • Interlock switch

  • Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
  • Fry tanks: 14 in. W x 14 in. D
  • Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
  • 6 A, 1/3 HP
  • 115 V/60 Hz/1 ph
  • LP gas powered
  • 210,000 BTU

Specifications

Manufacturer Vulcan
Baskets 2
BTU per Fryer 70000
Capacity (lbs) 150
Food Type Breaded
Frypot Style Tube Type
Gas Type LP
Heat Gas
NEMA 5-15P
Number of Fry Pots 3
Oil Capacity (lb) 150
Oil Capacity/Fryer (lb) 50
Product Gas Fryers
Product Type Cooking Equipment
Rating Best
Series PowerFry3®
Special Features Casters Included - Uninstalled
Type Floor Model
Warranty 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in) 46.5
Weight 717.00
