Vulcan 3TR45CF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane
The Vulcan 3TR45CF gas fryer features three total vats that hold 45 to 50 pounds of oil each. Part of the PowerFry3® series, this unit features programmable controls that assist operators with adjusting temperatures between 200 and 390 degrees Fahrenheit. Its SoftStart® heat transfer system prevents scorching and conserves energy by lowering output to 105,000 BTU per hour during startup, while its ThreePass® heat transfer system yields 60 percent cooking efficiency and 72 percent thermal efficiency. To drop and retrieve breaded foods, each vat has twin baskets with plastic-coated handles.
Equipped with KleenScreen PLUS® technology, the Vulcan 3TR45CF gas fryer offers adept filtration that extends oil life by 200 to 400 percent. This system's 1/3-horsepower motor circulates oil at 8 gallons per minute through both sides of a stainless steel filtration screen to remove sediment and small particulate that could affect oil life and taste. When oil needs to be replaced, it can be drained through the 1 1/4-inch port ball type drain valve into the 18-gauge stainless steel filter pan. Overall, this unit measures 46 1/2 inches wide by 30 1/8-inches-deep by 47 1/4 inches high and its cabinet and fry tank are constructed of stainless steel to reduce marring to the structure. It sits on a set of four 6-inch casters to ease maneuvering for cleaning or maintenance.
- Part of the PowerFry3® series
- 3-fryer battery
- Total capacity: 135-150 lb. (45-50 lb. per fryer)
- Twin baskets feature plastic-coated handles
- Stainless steel cabinet and fry tank
- (4) 6-in. adjustable casters
- Includes tank brush and clean-out rod
- Temperature range: 200-390 degrees F
- Programmable computer controls with melt cycles
- ThreePass heat transfer system
- Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
- SoftStart electronic ignition system
- KleenScreen PLUS filtration system
- 18-ga. stainless steel filter pan
- Stainless steel filter mesh screen
- 1 1/4-in. port ball type drain valve
- Interlock switch
- Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
- Fry tanks: 14 in. W x 14 in. D
- Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
- 6 A, 1/3 HP
- 115 V/60 Hz/1 ph
- LP gas powered
- 210,000 BTU
Specifications
| Manufacturer | Vulcan |
| Baskets | 2 |
| BTU per Fryer | 70000 |
| Capacity (lbs) | 150 |
| Food Type | Breaded |
| Frypot Style | Tube Type |
| Gas Type | LP |
| Heat | Gas |
| NEMA | 5-15P |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 150 |
| Oil Capacity/Fryer (lb) | 50 |
| Product | Gas Fryers |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | PowerFry3® |
| Special Features | Casters Included - Uninstalled |
| Type | Floor Model |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Width (in) | 46.5 |
| Weight | 717.00 |
