Vulcan 3TR45CF Gas Fryer - (3) 50 Lb Vats, Floor Model, Natural Gas
The Vulcan 3TR45CF gas fryer's temperature can be adjusted between 200 and 390 degrees Fahrenheit with its programmable computer controls; for operator convenience, these digital controls can also save 10 menu timers and display product name and cook times. This unit outputs 210,000 BTU per hour, but its SoftStart® electronic ignition lowers output to 105,000 BTU per hour during startup to prevent scorching. Its 14-inch-wide by 14-inch-deep fry tanks are heated with its ThreePass&trade heat transfer system which yields 60.9 percent cooking efficiency and 72 percent thermal efficiency. To adapt to a variety of culinary needs, its three fat melt modes can accommodate different shortening types. For an extended oil life, its KleenScreen PLUS® filtration system features a 1/3-horsepower motor that circulates 8 gallons of oil per minute through its stainless steel mesh screen to remove sediment and small particulate.
Overall, the Vulcan 3TR45CF fryer measures 46 1/2 inches wide by 30 1/2 inches deep by 47 1/8 inches high and features three 45- to 50-pound-capacity fry vats. Its fry tank and cabinet are constructed of stainless to withstand intense settings and resist corrosion. This unit includes two twin fry baskets to simplify the insertion or removal of breaded foods, and because they feature plastic-coated handles, they minimize operator burn risks. To assist with cleaning, its 1 1/4-inch port ball type drain valve facilitates oil removal, and it ships with a tank brush and clean-out rod. To maneuver this heavy-duty unit for maintenance or cleaning, it's mounted on a set of four 6-inch castersa€”two of which lock for stability.
- Part of the PowerFry3® series
- Oil capacity: 45-50 lb. per fryer (135-150 lb. total)
- Twin baskets feature plastic-coated handles
- Stainless steel cabinet and fry tank
- (4) 6-in. adjustable casters
- Includes tank brush and clean-out rod
- Temperature range: 200-390 degrees F
- Programmable computer controls with 3 melt modes
- 10 menu timers with digital display
- Offline programming available through USB (software included)
- Can cook with compensating or actual time
- ThreePass heat transfer system
- Outputs just 4,318 BTU/hr. when idle to maintain cooking temperatures
- SoftStart electronic ignition system
- KleenScreen PLUS filtration system
- 18-ga. stainless steel filter pan
- Stainless steel mesh filter screen
- 1 1/4-in. port ball type drain valve
- Interlock switch
- Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
- Fry tanks: 14 in. W x 14 in. D
- Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
- 6 A, 1/3 HP
- 115 V/60 Hz/1 ph
- Natural gas powered
- 210,000 BTU
Specifications
| Manufacturer | Vulcan |
| Baskets | 2 |
| BTU per Fryer | 70000 |
| Capacity (lbs) | 150 |
| Food Type | Breaded |
| Frypot Style | Tube Type |
| Gas Type | NG |
| Heat | Gas |
| NEMA | 5-15P |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 150 |
| Oil Capacity/Fryer (lb) | 50 |
| Product | Gas Fryers |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | PowerFry3® |
| Special Features | Casters Included - Uninstalled |
| Type | Floor Model |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Width (in) | 46.5 |
| Weight | 717.00 |
