Vulcan 3TR45DF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane

SKU 3TR45DF-LP
Original price $0.00 - Original price $0.00
Original price $0.00
$45,984.00
$45,984.00 - $45,984.00
Current price $45,984.00

The Vulcan 3TR45DF gas fryer has three fry pots with 45- to 50-pound oil capacities. This unit features a three-battery configuration, meaning each fryer shares a gas connection and filtration system. It's powered by liquid propane, which heats faster than natural gas alternatives. To preserve oil quality, its KleenScreen PLUS® filtration system features a 1/3-horsepower motor with a stainless steel mesh screen that filters oil from two sides to remove small particulate and sediment. Its temperature can be adjusted between 200 and 390 degrees Fahrenheit with its solid-state controls, and for accurate monitoring, it features a digital read-out display. To conserve energy, this fryer's SoftStart&trade electronic ignition reduces output to 105,000 BTU per hour during startup, and it features a ThreePass® heat transfer system that yields 72 percent thermal efficiency with 60.9 percent cooking efficiency.

Overall, the Vulcan 3TR45DF floor model fryer measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/4 inches high. The cabinet and fry tank are constructed of stainless steel, which means it's durable and minimizes irregularities to the structure. For accuracy, this unit includes two countdown timers that can track actual or compensating time to account for temperature fluctuations. To assist employees with dropping and removing breaded chicken and fish or mozzarella sticks and fries, each vat comes with twin baskets that have plastic-coated handles to minimize heat transfer to employees' palms. When oil needs to be discarded, its 1 1/4-inch port ball type drain valve facilitates emptying , while its tank brush, auto boil-out mode, and clean-out rod assist with cleaning. To ease maneuvering, it's mounted on four 6-inch casters.

  • Part of the PowerFry3® series
  • 3-battery frying system
  • Capacity per fryer: 45-50 lb. (135-150 lb. total)
  • Twin baskets feature plastic-coated handles
  • Stainless steel cabinet and fry tank
  • (4) 6-in. adjustable casters
  • Includes tank brush and clean-out rod

  • Temperature range: 200-390 degrees F
  • Solid-state digital controls
  • 3 melt modes for different fat types
  • 2 countdown timers can show compensating or actual time
  • Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
  • ThreePass heat transfer system
  • SoftStart electronic ignition system
  • Hi-limit shut off

  • 18-ga. stainless steel filter pan
  • Stainless steel mesh screen
  • Circulates 8 gallons of oil per minute
  • 1 1/4-in. port ball type drain valve
  • Interlock switch

  • Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
  • Fry tanks: 14 in. W x 14 in. D
  • Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
  • 6 A, 1/3 HP
  • 115 V/60 Hz/1 ph
  • LP gas powered
  • 210,000 BTU

Specifications

Manufacturer Vulcan
Baskets 2
BTU per Fryer 70000
Capacity (lbs) 150
Food Type Breaded
Frypot Style Tube Type
Gas Type LP
Heat Gas
NEMA 5-15P
Number of Fry Pots 3
Oil Capacity (lb) 150
Oil Capacity/Fryer (lb) 50
Product Gas Fryers
Product Type Cooking Equipment
Rating Best
Series PowerFry3®
Special Features Casters Included - Uninstalled
Type Floor Model
Warranty 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in) 46.5
Weight 717.00
