Vulcan 3TR65AF Gas Fryer - (3) 70 Lb Vats, Floor Model, Liquid Propane

SKU 3TR65AF-LP
Original price $0.00 - Original price $0.00
Original price $0.00
$46,359.00
$46,359.00 - $46,359.00
Current price $46,359.00

Part of the PowerFry3® series, the Vulcan 3TR65AF gas fryer is a three-battery unit that holds 65 to 70 pounds of oil per vat. While it outputs 210,000 BTU total, it lowers output to 105,000 BTU per hour during startup to conserve energy and prevent scorching. Meanwhile, its ThreePass® heat transfer system evenly distributes heat throughout the oil, yielding 60.9 percent cooking efficiency and 72 percent thermal efficiency . Each vat includes twin baskets with plastic-coated handles to reduce heat transfer to employees' palms. Its fry tank and cabinet are constructed of stainless steela€”which means it's durable and corrosion-resistanta€”and it measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/4 inches high overall.

The Vulcan 3TR65AF gas fryer's temperature can be set between 200 and 390 degrees Fahrenheit with its solid-state analog control knobs located behind the doors. This unit has integrated KleenScreen PLUS® filtration with a 1/3-horsepower motor that circulates 8 gallons of oil per minute. This system's stainless steel mesh screen removes small sediment are particulate, and when oil needs emptied, its 1 1/4-inch ball type drain valve facilitates removal. To further assist operators with cleaning, this fryer includes a tank brush and clean-out rod.

  • Part of the PowerFry3 series
  • Battery system with 3 fryers
  • Capacity per fryer: 65-70 lb. (195-210 lb. total)
  • ThreePass heat transfer system
  • Twin baskets with plastic-coated handles
  • Stainless steel cabinet and fry tank
  • Outputs 5,083 BTU/hr. when idle to maintain cooking temperatures
  • (4) 6-in. adjustable casters

  • KleenScreen PLUS filtration system
  • 18-ga. stainless steel filter pan
  • Stainless steel filter mesh screen
  • Drain valve interlock switch
  • 1 1/4-in. port ball type drain valve

  • Knob controls behind doors
  • Temperature control: 200-390 degrees F
  • User-selectable fat melt modes
  • SoftStart® ignition system

  • Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
  • Fry tanks: 19 1/2 in. W x 14 in. D
  • Overall: 63 in. W x 30 1/8 in. D x 47 1/4 in. H
  • 6 A, 1/3 HP
  • 115 V/60 Hz/1 ph
  • LP gas powered
  • 240,000 BTU

Specifications

Manufacturer Vulcan
Baskets 2
BTU per Fryer 80000
Capacity (lbs) 210
Food Type Breaded
Frypot Style Tube Type
Gas Type LP
Heat Gas
NEMA 5-15P
Number of Fry Pots 3
Oil Capacity (lb) 210
Oil Capacity/Fryer (lb) 70
Product Gas Fryers
Product Type Cooking Equipment
Rating Best
Series PowerFry3®
Special Features Casters Included - Uninstalled
Type Floor Model
Warranty 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in) 63
Weight 916.00
