Vulcan 3TR85AF Gas Fryer - (3) 90 Lb Vats, Floor Model, Liquid Propane

SKU 3TR85AF-LP
Original price $0.00 - Original price $0.00
Original price $0.00
$48,188.00
$48,188.00 - $48,188.00
Current price $48,188.00

Part of the PowerFry3® series, the Vulcan 3TR85AF gas fryer features an integrated KleenScreen PLUS® filtration system that circulates 8 gallons of hot frying compound per minute to upkeep oil. Because this is a three-battery unit, it's ideal for high-volume cooking as it holds 90 pounds of oil per vat. While operators prepare fries, breaded chicken, fish, and other meats, its ThreePass® heat transfer system evenly distributes heat throughout the oil for consistency. Overall, this fryer outputs a total of 270,000 BTU, but its SoftStart® electronic ignition lowers output to 135,000 BTU per hour during startup to prevent scorching. To set temperatures between 200 and 390 degrees Fahrenheit, operators can use the unit's solid-state analog knob controls.

Overall, the Vulcan 3TR85AF gas fryer measures 63 inches wide by 34 3/8 inches deep by 47 1/4 inches high. Its stainless steel cabinet and fry tank are ideal for intense settings because it's durable and corrosion resistant. To ease the removal of old oil, this unit includes a 1 1/4-inch ball type drain valve. Its included tank brush and clean-out rod are great for precise cleaning, and since it sits on four 6-inch casters, it can be wheeled out of the way to clean the floor.

  • Part of the PowerFry3 series
  • Battery system with 3 fryers
  • 255-270 lb. total capacity (85-90 lb. per fryer)
  • Twin baskets feature plastic-coated handles
  • Stainless steel cabinet and fry tank
  • Outputs just 5,575 BTU per hour when idle to maintain cooking temperatures
  • Includes tank brush and clean-out rod
  • (4) 6-in. adjustable casters

  • Temperature range: 200-390 degrees Fahrenheit
  • Solid-state analog controls with melt cycles
  • ThreePass heat transfer system
  • SoftStart electronic ignition system

  • KleenScreen PLUS filtration system
  • 18-ga. stainless steel filter pan
  • Stainless steel mesh screen
  • 1 1/4-in. port ball type drain valve
  • Interlock switch

  • Twin baskets: 8 1/4 in. W x 16 1/4 in. D x 6 in. H
  • Fry tanks: 19 1/2 in. W x 18 1/4 in. D
  • Overall: 63 in. W x 34 3/8 in. D x 47 1/4 in. H
  • 6 A, 1/3 HP
  • 115 V/60 Hz/1 ph
  • LP gas powered
  • 270,000 BTU

Specifications

Manufacturer Vulcan
Baskets 2
BTU per Fryer 90000
Capacity (lbs) 270
Food Type Breaded
Frypot Style Tube Type
Gas Type LP
Heat Gas
NEMA 5-15P
Number of Fry Pots 3
Oil Capacity (lb) 270
Oil Capacity/Fryer (lb) 90
Product Gas Fryers
Product Type Cooking Equipment
Rating Best
Series PowerFry3®
Special Features Casters Included - Uninstalled
Type Floor Model
Warranty 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in) 63
Weight 968.00
