Vulcan 4VK65DF Gas Fryer - (4) 70 Lb Vats, Floor Model, Natural Gas

SKU 4VK65DF-NG
Original price $0.00 - Original price $0.00
Original price $0.00
$67,021.00
$67,021.00 - $67,021.00
Current price $67,021.00

The Vulcan 4VK65DF floor model gas fryer is a four-battery unit powered by natural gas and featuring an integrated KleenScreen Plus® filtration system. Each vat can hold 65 to 70 pounds of oil, and to extend oil life, it filtrates the frying compound at 8 gallons per minute. Its stainless steel mesh filter screens from two sides to cover 270 and 350 square inches, and once the oil is emptied through its 1 1/4-inch drain valve, the 18-gauge filter pan can hold 110 pounds. To clean the exterior, this unit includes a tank brush and clean-out rod.

Overall, this unit measures 84 inches wide by 30 1/8 inches deep by 47 1/4 inches high and is mounted on 6-inch casters, easing maneuvering on smooth or irregular floors alike. Its 19 1/2-inch-wide by 14-inch-deep fry tank is made of stainless steel for a durable and corrosion-resistant design. It comes with metal-constructed fry baskets (2 per frypot) that feature plastic-coated handles to reduce heat transfer to palms.

To cook high volumes of breaded meats or vegetables, the Vulcan 4VK65DF fryer unit upholds temperatures between 200 and 390 degrees Fahrenheit; for precise temperature control, it's operated with solid-state digital controls. If it exceeds its temperature limit, it has a hi-limit shutoff to reduce fire risks. It produces 320,000 BTUs total, but to conserve energy, its SoftStart® ignition heats the system at just half that rate. Meanwhile, its FivePass® heat transfer yields 78 percent thermal efficiency and 68 percent cooking efficiency.

  • Part of the PowerFry5® series
  • 4 vats with 65-70-lb. capacity
  • 8 twin baskets with plastic handles (2 per frypot)
  • Stainless steel cabinet and fry tank
  • Adjustable casters (2 swivel locking & 2 non-locking)
  • 1 1/4-in. full port ball type drain valve
  • Includes tank brush and clean-out rod
  • SoftStart ignition system quickly heats oil at half the normal BTUs
  • FivePass heat transfer system evenly heats oil
  • (4) 80,000 BTUs

  • Temperature control: 200-390 degrees F
  • Can cook with actual time or compensating time
  • Three fat melt modes
  • Hi-limit shutoff

  • Motor and pump circulate oil at 8 gal. per minute
  • 18-ga. stainless steel filter pan
  • Two-sided stainless steel filter mesh screen
  • Boil-out bypass function
  • Interlock switch shuts off burners during filtration

  • Tank size: (4) 19 1/2 in. W x 14 in. D
  • Baskets: (8) 9 1/4 in. W x 13 1/4 in. D x 6 in. H
  • Overall: 84 in. W x 30 1/8 in. D x 47 1/4 in. H
  • 120 V/60 Hz/1 ph, with NEMA 5-15 P
  • 7 A, 1/3-HP motor
  • 1 1/4 NPT common rear gas connection
  • Powered by natural gas

Specifications

Manufacturer Vulcan
Baskets 2
BTU per Fryer 320000
Capacity (lbs) 280
Food Type Breaded
Frypot Style Tube Type
Gas Type NG
Heat Gas
NEMA 5-15P
Number of Fry Pots 4
Oil Capacity (lb) 280
Oil Capacity/Fryer (lb) 70
Product Gas Fryers
Product Type Cooking Equipment
Rating Best
Series PowerFry5®
Special Features Casters Included - Uninstalled
Type Floor Model
Warranty 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in) 84
Weight 1136.00
