RICE LAKE IQ+210-2A DIGITAL INDICATOR WEIGHT SCALE 115V-AC

The Rice Lake IQ+210-2A indicator paired with the BM1010S-30 bench scale creates a durable, accurate weighing system designed specifically for industrial and commercial applications in harsh environments. The IQ+210-2A is a rugged, stainless steel digital indicator featuring an LED display, IP66 rating, RS-232 communication port, and 2 digital inputs. The BM1010S-30 is a light-capacity, 10"x10" stainless steel bench scale with a 30 lb (15 kg) capacity, featuring an NTEP certified aluminum load cell designed for precision in demanding settings. Together, these components create a complete weighing solution capable of handling washdowns and the most challenging operating environments.

IQ+210-2A Digital Indicator

• 6-Digit LED Display - 0.8 inch LED display with 1:10,000 resolution for precise readings
• Stainless Steel Housing - NEMA 4X/IP66 rated construction for harsh environment protection
• Full Duplex RS-232 Communication - Standard serial port for data transmission and connectivity
• 2 Digital Inputs - Remote zero, print, and units control capabilities

BM1010S-30 Bench Scale (BenchMark SL Series)

• 30 lb (15 kg) Capacity - Light-capacity design ideal for precision weighing applications
• 10" x 10" Stainless Steel Platform - Durable 254mm x 254mm weighing surface
• NTEP Certified Aluminum Load Cell - Single-point, IP66 rated load cell for accuracy and reliability
• Class III/IIIL Approval - NTEP certified for legal-for-trade applications

Key Features & Benefits

Industrial-Grade Construction

• Stainless Steel Components - Both indicator and scale platform constructed from stainless steel for durability and corrosion resistance
• IP66 Rating - Complete protection against dust and powerful water jets, suitable for washdown environments
• NEMA 4X Housing - Indicator housing rated for indoor/outdoor use in corrosive environments
• Overload Stops - Built-in protection prevents damage from excessive loads

Easy Operation & Control

• 2 Piezo Keys - Simple Zero and Units control buttons on indicator
• Multiple Unit Capabilities - Displays in lb, kg, oz, g, or lb-oz formats
• Remote Control Options - 2 digital inputs allow for remote zero, print, and units switching
• Easy-Clean Design - Smooth surfaces and minimal crevices facilitate quick cleaning

Advanced Features

• PreVent® Breather System - Prevents moisture intrusion while allowing pressure equalization
• High Resolution - 1:10,000 resolution ensures precise weight measurements
• Load Cell Drive Capacity - Supports up to 4 x 350 ohm load cells
• Dual Voltage Power - Compatible with 115 VAC or 230 VAC power supplies

Communication & Connectivity

• Full Duplex RS-232 Port - Standard serial communication for printers, computers, and data collection systems
• Digital Input Control - External triggering for remote operation and automation
• Print Function - Direct connection capability for weight ticket printing

How the System Works

The IQ+210-2A indicator provides the processing power and display capabilities, connecting directly to the BM1010S-30 scale platform which acts as the sensing element. When an item is placed on the stainless steel platform, the NTEP certified aluminum load cell measures the weight and transmits the signal to the indicator. The indicator processes this information and displays the weight on the bright LED display in the selected unit of measure. This integrated system creates a complete, durable, and accurate weighing solution designed for industrial and commercial applications.

Ideal Applications

This professional weighing system is perfectly suited for:

• Food Processing Facilities - NTEP certification and washdown capability for food safety compliance
• Restaurants & Commercial Kitchens - Portion control and recipe scaling
• Manufacturing Operations - Quality control and production weighing
• Packaging Operations - Precise weight verification and filling
• Laboratories - Accurate measurements in controlled environments
• Retail Operations - Legal-for-trade certified for commercial sales
• Shipping & Receiving - Package verification and documentation

IQ+210-2A Indicator Specifications

• Display: 6-digit, 0.8" LED with 1:10,000 resolution
• Housing: Stainless Steel, NEMA 4X/IP66 rated
• Controls: 2 piezo keys (Zero, Units)
• Digital Inputs: 2 inputs (remote zero, print, units)
• Communication: Full Duplex RS-232
• Load Cell Support: Up to 4 x 350 ohm load cells
• Units of Measure: lb, kg, oz, g, lb-oz
• Power: 115/230 VAC

BM1010S-30 Scale Specifications

• Model: BenchMark SL Series BM1010S-30
• Capacity: 30 lb (15 kg)
• Platform Size: 10" x 10" (254mm x 254mm)
• Platform Material: Stainless Steel
• Load Cell Type: Aluminum, single-point
• Load Cell Rating: IP66 rated
• Protection Features: PreVent® breather, overload stops
• Design: Easy-clean construction
• Certifications: NTEP certified Class III/IIIL
• Legal for Trade: Yes

Why Choose This Rice Lake System?

This complete weighing system combines Rice Lake's renowned quality and precision engineering in a package designed specifically for harsh environments. The NEMA 4X/IP66 rated stainless steel indicator paired with the IP66 rated stainless steel platform ensures reliable operation even in washdown environments common in food processing and manufacturing facilities.

The NTEP certification makes this system legal for trade applications, while the easy-clean design, PreVent® breather system, and overload protection ensure long-term reliability with minimal maintenance. The 1:10,000 resolution provides precise measurements, and the multiple unit display options offer flexibility for various applications. The RS-232 communication port enables integration with printers and data collection systems for complete documentation and traceability.

Experience precision, durability, and reliability with Rice Lake weighing systems - the trusted choice for demanding industrial and commercial applications worldwide.
