Southbend 4601DD-2GL 60" 6 Burner Gas Range W/ Griddle & (2) Standard Ovens, Natural Gas
Part of the Ultimate Restaurant Range series, the Southbend 4601DD-2GL range combines three essential methods of cooking to create one highly versatile piece of restaurant equipment. The 60-inch cook top consists of six 33,000-BTU open burners with cast iron grates and a 24-inch griddle with a 0.5-inch-thick griddle plate that heats quickly and evenly. This restaurant range's two standard ovens each come with their own oven rack, which are adjustable in two positions. These ovens also accommodate full-size sheet pans in both directions.
To endure daily scuffs, scrapes, and dents, the Southbend 4601DD-2GL commercial range has a corrosion-resistant stainless steel exterior. A 4-inch stainless steel rail lines the front of the burners, providing a plating area and a barrier between the operator and hot surfaces. Inside the oven, the porcelain enamel resists corrosion for a long service life, and its smooth surface is easy to clean. Its coved corners help evenly circulate airflow, preventing cold spots that could impact results. For high-volume loads, the oven's interior measures 26 inches wide by 26.5 inches deep by 14 inches high. Overall, this unit is 60.75 inches wide by 34 inches deep by 59.5 inches high.
Specifications
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Standard Oven |
| BTU / Burner | 33000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Manual |
| Depth (in) | 34 |
| Gas Inlet Size | 0.75 |
| Gas Type | NG |
| Griddle Location | Left |
| Griddle Width (in) | 24 |
| Heat | Gas |
| Height (in) | 59.5 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 6 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 33000 |
| Plate Thickness (in) | 1/2 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Standard Oven | 2 |
| Racks per Standard Oven | 1 |
| Range Configuration | Burners/Griddle |
| Rating | Better |
| Series | Ultimate |
| Special Features | Spark Ignition |
| Standard Oven BTU/hr | 45000 |
| Standard Oven Dimensions | 26"W x 26.5"D x 14"H |
| Total BTU | 336000 |
| Vent | Backriser w/ hi-shelf |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
