Southbend 4601DD-2GR 60" 6 Burner Gas Range W/ Griddle & (2) Standard Ovens, Natural Gas
The Southbend 4601DD-2GR gas range has two standard ovens in its base, with each accommodating a full-size pan inserted front to back. Interiors are coated in porcelain enamel to resist corrosion and simplify cleaning, and each oven has one rack with two side rails to accommodate various pan sizes. Temperatures range in the oven from 175 to 550 degrees Fahrenheit.
On the top are six burners and a 24-inch griddle that has a 1-inch-thick, polished steel plate with raised edges to capture messes. The griddle sits on the right side of the unit and measures 24 inches wide, while the knobs have manual markings that read "Low, Medium, and High." Six non-clog burners on the range top are made of cast iron, and cast iron grates covering the burners heat evenly and withstand heavy use. The 4-inch front rail protects operators from burns and gives them a place to put food on plates, while the Southbend 4601DD-2GR gas range is heated with natural gas.
Specifications
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Standard Oven |
| BTU / Burner | 33000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Manual |
| Depth (in) | 34 |
| Gas Inlet Size | 0.75 |
| Gas Type | NG |
| Griddle Location | Right |
| Griddle Width (in) | 24 |
| Heat | Gas |
| Height (in) | 59.5 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 6 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 33000 |
| Plate Thickness (in) | 1/2 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Standard Oven | 2 |
| Racks per Standard Oven | 1 |
| Range Configuration | Burners/Griddle |
| Rating | Better |
| Series | Ultimate |
| Special Features | Spark Ignition |
| Standard Oven BTU/hr | 45000 |
| Standard Oven Dimensions | 26"W x 26.5"D x 14"H |
| Total BTU | 336000 |
| Vent | Backriser w/ hi-shelf |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
