Structural Concepts NE3627RSSV 35 3/4" Reveal® Drop-In Vertical Open Air Cooler W/ (3) Levels, 110-120v
The Structural Concepts NE3627RSSV drop-in refrigerated display case is designed for high-volume sales because it features three tiers with adjustable shelves. This display case measures 353/4 inches wide by 33 inches deep by 471/8 inches high; 277/8 inches are visible above the countertop, and the internal mechanics hidden from the patron's line of sight. Meant to slide into a countertop cutout, it's cooled by a compressor using an energy-efficient motor. Additionally, its evaporator coil is coated in Blue Fin polymer to protect against mechanical issues. It's also equipped with a condensation pan to catch water and reduce the chance of rusting. With its Breeze-E temperature control system, this open-air unit can hold products at or below 40 degrees Fahrenheit.
Constructed to encourage last-second purchases near checkout areas, the Structural Concepts NE3627RSSV open-air display case is lit by LEDs. Its sides are made of glass, while its solid black back plate highlights the vibrant colors of item packaging. If it needs to accommodate larger items, all shelves are completely adjustable and removable.
Reveal® Self-Service Refrigerated Slide In Counter Case, 35-3/4"W, 27-7/8"H (above counter) 47-1/4"H (overall), Breeze-E (Type II) with EnergyWise self-contained refrigeration, (2) removable & adjustable clear glass shelving, LED top & shelf lights, slide in base, glass ends, upper rear solid back panel, coated coil, condensate pan, cETLus, ETL-Sanitation
*Image may not depict product color, inclusions or accessories.
Important Prop 65 information for California residents.
Specifications
| Manufacturer | Structural Concepts |
| Color | Black |
| Compressor Type | Self Contained |
| Depth (in) | 33 |
| Design | Vertical |
| Height (in) | 27.88 |
| Hertz | 60 |
| NEMA | 5-20P |
| NEMA | L5-20P |
| Number of Levels | 3 |
| Phase | 1 |
| Product | Open Air Merchandisers |
| Product Type | Commercial Refrigeration |
| Rating | Best |
| Refrigerant | R290 (Hydrocarbon) |
| Series | Reveal® |
| Special Features | Black Interior |
| Special Features | Glass Sides |
| Special Features | LED Lighting |
| Voltage | 110/120 |
| Warranty | 1-year Limited Parts & Labor; 5-year Compressor |
| Width (in) | 35.75 |
| Weight | 750.00 |
