Vulcan K20ELT 20 Gal Steam Kettle - Manual Tilt, 2/3 Jacket, 240v/3ph

SKU K20ELT-2403
Original price $0.00 - Original price $0.00
Original price $0.00
$32,756.00
$32,756.00 - $32,756.00
Current price $32,756.00

Supported by a tri-leg base, the Vulcan K20ELT electric tilting kettle remains stable during operation while facilitating easy access for cleaning after use. Designed for high-volume food preparation, its 20-gallon true working capacity and 2/3-jacketed construction provide even steam distribution. A spring-assisted, hinged stainless steel cover with a condensate ring and a drop-down lift handle helps retain heat and moisture, while the manual tilt mechanism enables smooth pouring.

The Vulcan K20ELT tilting kettle includes a 2-inch compression tangent draw-off valve with a perforated strainer for efficient dispensing and flow control. The interior features embossed gallon and liter markings to simplify measurement. The stainless steel enclosure houses water-resistant controls, including a power switch, power-on light, solid-state temperature control, a vacuum/pressure gauge, a pressure relief valve, a low water light, and a low water shut-off.

  • 20-gal. true working capacity
  • Stainless steel construction
  • 2/3-jacketed floor-mounted design
  • Tri-leg base with tubular stainless steel legs and flanged feet
  • Spring-assist hinged stainless steel cover with condensate ring
  • Drop-down lift handle with heavy-duty pivot assembly
  • Manual tilt mechanism
  • 2-in. compression tangent draw-off valve with perforated strainer
  • Embossed gallon and liter markings
  • Faucet bracket on tilting console
  • Stainless steel enclosure for water-resistant controls
  • Simple power switch
  • Power indicator light
  • Solid-state temperature control
  • Vacuum/pressure gauge
  • Pressure relief valve
  • Low water light and low water shut-off
  • 50-PSI steam jacket rating

  • 35 3/4 in. W x 25 3/4 in. D x 53 1/2 in. H
  • 240 V/60 Hz/3 ph

Specifications

Manufacturer Vulcan
Base Tri Leg
Capacity (gallons) 20
Design 2/3 Jacket
Heat Electric
Hertz 60
No. of Kettles 1
Phase 3
Series KELT Series
Tilt Mechanism Crank
Type Floor Model
Voltage 240
Warranty 1-year Limited Parts & Labor
Weight 296.00
