Vulcan V2B18B 18" 2 Burner Gas Range W/ Storage Base, Natural Gas

SKU V2B18B-NG
Original price $0.00 - Original price $0.00
Original price $0.00
$5,235.00
$5,235.00 - $5,235.00
Current price $5,235.00

The Vulcan V2B18B heavy-duty gas range measures 18 inches wide and is constructed of stainless steel on the stub back, plate ledge, front, sides, and the front top ledge which features pull-out condiment rails. The 6-inch legs are adjustable, and the 1 1/4-inch-diameter front gas manifold comes with a 1 1/4-inch rear capped gas connection. Its heavy cast aeration bowls are equipped with removable cast top grates.

This rangea€™s front grate measures 11 1/2 inches by 17 3/8 inches, the rear grate measuring 14 1/2 inches by 17 3/8 inches. The two heavy cast, two-piece open burners come with individual pilots and controls for independent operation, each generating 35,000 BTU per hour. Total input for this gas range comes to 70,000 BTU per hour.

The Vulcan V2B18B gas range requires minimal space, so it can be used in fine dining kitchens and restaurants with a broad menu selection, as well as in smaller kitchen institutions like clubs and churches. It is commonly used for braising, sautA©ing, pan-frying, boiling, and stock pot cooking. The unit supports pots and pans above the burner, as the gas flame rises to meet the bottom of the pot or pan.

  • Stainless steel sides, front, plate ledge, stub back
  • Front top ledge has pull-out condiment rails
  • 6-in. stainless steel legs are adjustable
  • 1 1/4-in.-diameter front gas manifold with 1 1/4-in. rear capped gas connection
  • Heavy cast aeration bowls equipped with removable cast top grates
  • (2) 35,000 BTU heavy cast, 2-piece open burners
  • Burners have individual pilots and controls

  • Front grate: 17 3/8 in. W x 11 1/2 in. D
  • Rear grate: 17 3/8 in. W x 14 1/2 in. D
  • Overall: 18 in. W x 36 3/4 in. D x 42 in. H
  • Powered by natural gas

Specifications

Manufacturer Vulcan
Additional Info Contact Customer Service for altitudes above 2,000 feet
Application Heavy Duty
Base Storage
BTU / Burner 35000
Burner Configuration Standard
Burner Style Grates
Burner Type(s) Open
Controls Manual
Depth (in) 36.75
Gas Inlet Size 1.25
Gas Type NG
Heat Gas
Height (in) 36
Installation Type Freestanding
Number of Burners 2
Number of Ovens No Oven
Open Burner BTU (ea) 35000
Product Gas Ranges
Product Type Cooking Equipment
Racks per Standard Oven No Rack
Range Configuration Burners
Rating Best
Series V Series
Total BTU 70000
Vent Stub Riser
Warranty 1-year Limited Parts & Labor
Width (in) 18
Weight 225.00
