Vulcan V2BG8TC 36" 2 Burner Gas Range W/ Griddle & Convection Oven, Natural Gas
To save space and eliminate the need to purchase three separate pieces of equipment, the Vulcan V2BG8TC gas range measures 36 inches wide by 41 7/8 inches deep by 40 1/2 inches tall; it features two open-top burners, an 18-inch-wide griddle, and a convection oven. Because its front, top ledge, sides, base, and stub back are made of durable stainless steel, it withstands heavy-duty use in fast-paced restaurant kitchens. For stabilization on uneven flooring, it's positioned on 6-inch legs that can be raised or lowered to reduce the risk of wobbling or rocking during use.
The two open-top burners positioned on the unit's left side each output 35,000 BTUs and have individual pilots and controls to enable simultaneous cooking of different dishes. Both burners feature heavy-duty cast grates, with the front grate measuring 11 inches by 17 inches to support small- or medium-size cookware, and the rear grate measuring 14 inches by 17 inches to accommodate stock pots or saucepans. To ease cleaning, this range includes an extra-deep stainless steel crumb tray, and the lift-off grates are separate from the aeration bowl. On the top section's right side, the 18-inch-wide right-side griddle is built with one 30,000-BTU burner and a 3/4-inch-thick ground-steel griddle plate capable of withstanding repeated heating and cooling. Operators can precisely adjust the griddle plate's heat with the snap-action thermostatic controls.
The Vulcan V2BG8TC heavy-duty range's base features a convection oven that uses a fan to circulate heat for quick, uniform baking, roasting, broiling, or rethermalizing. Operators can set the temperature from 175 to 550 degrees Fahrenheit with the corresponding thermostat. This 32,000-BTU unit features a porcelain base, sides, and an interior door panel to ease cleaning, while its heavy-duty counterweight door hinge simplifies pan insertion and removal. Its 27-inch-wide by 27-inch-deep by 13-inch-tall interior includes two racks that can be raised or lowered in three positions to achieve various results.
- Part of Vulcan's V series
- Stainless steel front, front top ledge, sides, base, and stub back
- (2) 35,000-BTU open-top burners with lift-off heads
- Individual pilots and controls for each burner
- Heavy-duty lift-off cast grates
- 11-in. x 17-in. front grate
- 14-in. x 17-in. rear grate
- Stainless steel extra-deep crumb tray
- 18-in.-wide griddle
- 3/4-in.-thick ground steel griddle plate
- Snap-action thermostatic controls enable precise adjustment
- 6-in. adjustable stainless steel legs
- Operating temperature: 175-500 degrees F
- Porcelain base, sides, and interior door panel
- Includes 2 racks that can be placed in 3 positions
- 1 hinged counterweight door
- 32,000 BTU
- Oven interior: 27 in. W x 27 in. D x 13 in. H
- Overall: 36 in. W x 36 3/4 in. D x 36 in. H
- 4 A
- 115 V/60 Hz/1 ph, 6-ft. cord with plug
- Powered by natural gas
- 1 1/4-in. diameter front gas manifold
- 1 1/4-in. rear gas connection
- 132,000 BTU
Specifications
| Manufacturer | Vulcan |
| Application | Heavy Duty |
| Base | Convection Oven |
| BTU / Burner | 35000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Thermostatic |
| Depth (in) | 36.75 |
| Gas Type | NG |
| Griddle Width (in) | 18 |
| Heat | Gas |
| Height (in) | 36 |
| Installation Type | Freestanding |
| Number of Burners | 2 |
| Number of Ovens | Single |
| Plate Thickness (in) | 3/4 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 3 |
| Racks per Convection Oven | 2 |
| Range Configuration | Burners/Griddle |
| Rating | Best |
| Series | V Series |
| Total BTU | 132000 |
| Vent | Stub Back |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 36 |
| Weight | 691.00 |
